- Place of Origin:CN;ZHE
- Nominal Voltage:1.5V
- Brand Name:3G/ OEM
- Size:AA
- Nominal Capacity:1200mAh
- Battery Type:Zn/MnO2
- Model Number:AA/UM-3/R6
| Product name | UM-3/R6/AA dry battery |
| Chemical System | Carbon-zinc (Zn-MnO2) battery |
| Standard | IEC standard |
| Nominal voltage | 1.5V |
| Size | AA |
| Jacket | PVC |
| Shelf life | 3 years |
1.Electrical Requirement
O.C.V Min 1.65 Max 1.725
C.C.V >1.450V
After 0.2 sec +/- 0.01 sec by R=5.0Ω
2.Service Life :
Discharge test result as follow (condition: +20°C+/-2°C and 60+/-15% RH).
Test condition | Duration |
3.9Ω,24h/d,0.9V | 100min |
10Ω, 24h/d,0.9V | 370min |
1.8Ω,15s/min,24h/d,0.9V | 175cycles |
3.9Ω,1h/d,0.8V | 2.4h |
43Ω,1h/d,0.9V | 30h |
10Ω,1h/d,0.9V
| 6.6h |
3. Leakage Resistance & Safety Requirement Test
High heat and humidity storage test | High Temperature Exposure When exposed to a temperature of 60 +/-2 ℃,60+/-15% RH for a period of 20days | No leakage |
